The popular ST-500 inline fluorometer is a robust and highly accurate tool for real-time monitoring of inhibitor dose. It is often used for feedback control to maintain dosed concentration within a narrow band around the set point, regardless of changes in cycle or heat load dynamics. Now the ST-500 series includes expanded measurement targets for a broad range of analytes, including fluorescein and naphthenic disulfonic acid (NDSA), and brings its proven record of reliability to your traced cooling programs for boiler and other applications. Thanks to its state-of-the-art fluorescence technology, the ST-500 Series handles a wide range of real-world sample water conditions. With its flow-through optical design and multiple wavelength color-turbidity compensation algorithm, the ST-500 probe maintains high performance for water samples with up to 100 NTU turbidity and/or 5 ppm iron. The competitive probe comparison shown in the experiment below clearly demonstrates the superior performance of the ST-500 probe in the presence of iron color. Typical Applications Traced cooling water treatment programs Traced boiler water treatment programs Features Color and turbidity compensation for accurate readings, long-term stability, and less frequent calibration. Typical maintenance cycle in months, not weeks or days. Works with WiFi and Bluetooth adapters for one-press calibration with the SP-910, 700, and 400 tools, and for firmware upgrades via your smart phone. Isolated 4-20mA output: no need for additional transmitter for easy connection with PLC and DCS. Specifications ST-500(1) ST-525/ST-525SS(2) ST-540 P/N 50661 50665 50666 for SS 50667 Target PTSA Fluorescein NDSA Range 0~200 ppb 0~60 ppb 0~100 ppb Resolution 0.1 ppb Accuracy ±1% of reading or 1 ppb , whichever is greater Method UV Fluorescence Power Supply 22~26V DC,Power Consumption ~1W Outputs Isolated 4-20mA Analog Output Isolated RS-485 Digital Output Supporting MODBUS protocol Dimension Length 6.8 inch, diameter 1.44 inch 525SS: 8.3 x 2.25 x 1.75 inch Weight 0.37 lbs (525SS: 3.2 lbs) Installation Custom tee with 3/4″NPT ports Housing Material CPVC/stainless steel Pressure Up to 100 psi Temperature Operation 40~120℉,Storage 20~140℉ Cable Length 5 feet,terminated with IP67 connectors 30 feet, 60 feet extension cables available Calibration Two point calibration against standard solutions Rating IP66 Regulation CE marked Camlock version available. Stainless housing version available.Check www.pyxis-lab.com PYXIS INLINE PROBES – SELECT*A*GUIDE Functional Capability ST500 ST500SS ST500RO ST525 ST525ss ST540SS ST565 EM500 PTSA (0-300ppb) For Cooling ● ● PTSA (0-10ppb) For RO ● Fluoroscein (0-60ppb) For Process ● Fluoroscein (0-60ppb) For Boiler ● NDSA (0-100ppb) For Boiler ● HST (0-5ppm) For Cooling ● Chlorophyll-a (0-1000ppb) For Cooling ● Modbus RS 485 Output ● ● ● ● ● ● ● ● Analog 4-20mA Output ● ● ● ● ● ● ● ● MA-485WB Adapter Required For BlueTooth & Wifi Communication ● ● ● ● ● ● ● ●
