UniFi 6 Access Point WiFi 6 Pro (U6-Pro)

MechanicalDimensionsØ197 x 35 mm (Ø7.8 x 1.4″)WeightWithout mount: 580 g (1.3 lb) With mount: 720 g (1.6 lb)Enclosure materialPolycarbonateMount materialStainless steel (SUS304)WeatherproofingIP54HardwareNetworking interface(1) GbE RJ45 portManagement interfaceEthernet BluetoothPower methodPoEPower supplyUniFi PoE switch PoE adapter (Not included)Supported voltage range44—57V DCMax. power consumption13WMax. TX power 2.4 GHz 5 GHz 6 GHz 22 dBm 26 dBm –MIMO 2.4 GHz 5 GHz 6 GHz 2 x 2 (UL MU-MIMO) 4 x 4 (DL/UL MU-MIMO) –Throughput rate 2.4 GHz 5 GHz 6 GHz 573.5 Mbps 4.8 Gbps –Antenna gain 2.4 GHz 5 GHz 6 GHz 4 dBi 6 dBi –LEDsWhite/blueButtonFactory resetMountingWall, ceiling (Included)Ambient operating temperature-30 to 60° C (-22 to 140° F)Ambient operating humidity5 to 95% noncondensingCertificationsCE, FCC, ICSoftwareWiFi standards802.11a/b/g/n/ac/axWireless securityWPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)BSSID8 per radioVLAN802.1QAdvanced QoSPer-user rate limitingGuest traffic isolationSupportedConcurrent clients350 Zero wait DFSYes* *Supported with upcoming firmware versionsSupported Data Rates802.11a6, 9, 12, 18, 24, 36, 48, 54 Mbps802.11b1, 2, 5.5, 11 Mbps802.11g6, 9, 12, 18, 24, 36, 48, 54 Mbps802.11n (WiFi 4)6.5 Mbps to 600 Mbps (MCS0 – MCS31, HT 20/40)802.11ac (WiFi 5)6.5 Mbps to 3.4 Gbps (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80/160)802.11ax (WiFi 6)7.3 Mbps to 4.8 Gbps (MCS0 – MCS11 NSS1/2/3/4, HE 20/40/80/160)Application RequirementsUniFi NetworkVersion 6.1.56 and laterDatasheet
